Model: QR600-V, QR600-H

Dynamic QR RFID Reader For Access Control System

General Configuration:

Reads Dynamic QR Code
Compensation LED light for night use
Reads 13.56Mhz Card and cellphone NFC
Supports Chile & Argentina National ID PDF417 code
IP65 Waterproof and dustproof Case
WG34/26/66, RS485 Communication ports
Compatible with ZKTeco C3 controller and Inbio Controller

Description:

QR600-H &QR600-V from ZK are dynamic QR readers for access control system, with RFID reading function. The readers adopt advanced technology, reaching fast scanning speed at high accuracy rate. They are compatible with any access control panels that supports wiegand input. By default, they can recognize 13.56Mhz proximity card and QR code.

These QR readers are equipped with metal frame and toughened glass faceplate. The case meets IP65 waterproof standard with anti-exposion feature. These readers could be applied to wide applications, like Apartments Management, Visitors Management, Hotel Management, Self-service Supermarkets, Elevator System, etc

Specifications:

International StandardISO/IEC 14443A RS485 Protocol
QR Code StandardQR,  Data Matrix,  PDF417,  GS1 Databar,  Code 128/EAN128,  UPC/EAN, Codabar,  Code 39/Code 93
QR Code TypesElectronic QR Code, Paper QR Code, Dynamic QR Code
RFID CardUltralight,  MF1(S50,S70),  DESFire EV1,  NTag,  NFC,  CPU,  or ISO/IEC 14443A
Operation Frequency13.56 Mhz
Working Voltage12V (No more than 200mA), 5V USB (No more than 500mA)
Resolution 648×488
Reading DistanceRFID>5cm, QR 5.0-18.0cm (Depends on QR Code size , Light Intensity)
Speed100ms (On average)
CommunicationsWiegand (Default WG34),  RS485
MaterialMetal Frame, Toughened Glass
Working Temp -10℃~+50℃
Working Humidity 20% ~ 80%
Waterproof StandardIP65
Dimension QR600-V: 138*58*22.67mm
QR600-H: 120*80*22.67mm

QR600 QR RFID Reader Connection Diagram in Access Control System

QR600 QR reader connection diagram in the access control system

Multiple Options on QR Readers: QR600-H, QR600-HK, QR600-V, QR600-VK

QR600 QR reader connection diagram in the access control system

How does QR600 work with ZK Inbio and C3 Controller
