Model: RT383

Waterproof proximity Access Control

Main Features

* Waterproof case, suitable for outdoor environment
* Supporting 125Khz proximity card and Password verification
* Reaching 5000 RFID capacity and 5000 password capacity
* Mechanical Keyboards with Backlight
* Embedded Door Bell function
* With Wiegand 26/34 output, can work with control panel or standalone access control

Description:

RT383 from is a standalone waterproof proximity access control device. It reaches IP65 waterproof and dustproof level, which could be used for outdoor environment. It comes with 16 mechanical keyboards with backlight, suitable for for dark operation. The device supports fast verification with password and RFID cards. With big user capacity of 5000, you can use this model for a wide range of access control applications.

RT383 is not only a standalone device, but also can be used as slave readers for control panels like C3 and Inbio, and A&C standalone devices like F18, F19, F21, F22, TF1700. It is convenient to switch the device from access control mode to reader mode.

Specifications:

RFID Frequency 125KHz(Standard), 13.56MHz(Optional)
Protection Standard IP65
Operating Voltage DC9 - 14V
Operating Temperature -10°C ~ 60°C (14°F ~ 140°F)
Humidity Storage 15% ~ 90%
Dimensions (L*W*H) SKW-V: 160 * 50 * 20.5 (mm), SKW-H:120 * 86 * 20.5 (mm)
User Capacity5000
Password Capacity5000
Password Length4 to 6 digits
Verification Modes:Card Only / Password Only / Card + Password
Access Control Interface1 Relay, 1 Door Sensor, 1 Exit Button, 1 Doorbell, 1 Tamper Alarm
Wiegand Reader ModeW26/W34 Output

SKW Access Control Connection and Reader Connection
